Gesture Controlled Robotic Hand Using Arduino and Flex Sensors

Description

Flex Sensors → Arduino → Servo Motors → Robotic Hand Movement

Ideal for engineering students, BTech major projects, diploma projects, and school exhibitions

🧠 Introduction

Robotic manipulation systems have evolved significantly over the past several decades, transforming from simple industrial grippers into highly sophisticated anthropomorphic hands capable of mimicking human motion. Early robotic systems developed during the 1950s and 1960s were primarily designed for repetitive industrial tasks such as assembly, welding, and material handling. These systems were rigid, pre-programmed, and lacked adaptability. However, with advancements in embedded systems, microcontrollers, sensors, and affordable actuators, robotics has become increasingly accessible for research, medical rehabilitation, prosthetics, and educational applications.

A human hand is an extraordinarily complex biological structure composed of multiple joints, tendons, muscles, and sensory feedback mechanisms. Replicating this dexterity artificially remains one of the most challenging problems in robotics. Gesture-controlled robotic hands attempt to bridge this gap by capturing natural human finger movements and reproducing them mechanically using servo motors and control systems. Such systems are especially valuable in prosthetic research, teleoperation, hazardous environment handling, and assistive technologies.

This project presents a 3D-printed robotic hand controlled directly using flex sensors mounted on a wearable glove. Unlike wireless systems, this design uses a single Arduino microcontroller to read finger movements and control six servo motors in real time through wired connections.

Each flex sensor detects bending of a finger, converts it into analog voltage using a voltage divider circuit (10kΩ resistor), and sends the data to the Arduino. The Arduino processes the sensor values and directly drives corresponding servo motors, allowing the robotic hand to precisely mimic human gestures.

🎯 Objectives

• To design a real-time gesture-controlled robotic hand.

• To use flex sensors for detecting finger bending.

• To directly control servo motors using a single Arduino.

• To eliminate wireless communication for improved stability.

• To develop a low-cost prosthetic robotic hand model.

Block Diagram

Block Diagram of Gesture Controlled Robotic Hand Using Arduino and Flex Sensors

Components Used

Working Principle

1️⃣ Gesture Detection

• Each flex sensor changes resistance when bent.

• A 10kΩ resistor forms a voltage divider.

• Arduino reads analog values from A0–A4.

• Values are mapped from 0–1023 to 0°–180° servo angles.

2️⃣ Direct Servo Control

• Arduino directly sends PWM signals to:

  • 5 MG995/MG996 servos (fingers)

  • 1 small 9g servo (thumb)

• Each servo rotates proportional to finger bend.

• Real-time motion achieved without transmission delay.

3️⃣ Mechanical Motion

• Servos pull strings attached to fingers.

• When servo rotates → string tightens → finger bends.

• When released → finger extends back.

4️⃣ Power Management

• Servos powered through external battery.

• Arduino powered via regulated 5V.

• Common ground required.
