IOT Based Smart Parking System with Gate

Smart Shoes for Women Safety with Self Defence and Tracking System
IOT based Smart Green Parking and Wireless Charging System for Electric Vehicles

Original price was: ₹10,000.00.Current price is: ₹8,000.00.

The rapidily increasing number of vehicles have led to a critical challenge of efficient parking management in urban areas. To address this issue, we propose an IoT-based Smart Parking Monitoring System that utilizes IR sensors for detecting the occupancy of parking spaces and efficiently managing entry and exit at parking gates. The system aims to provide real-time information about parking space availability at online web browser.

YOUTUBE : https://www.youtube.com/shorts/Pjx4JUevjRo

  Ask a Question
Add to wishlist
Compare

Description

DESCRIPTION

The proposed system consists of two main components: parking space monitoring and gate monitoring. For parking space monitoring, IR sensors are deployed at strategic locations to detect the presence of vehicles in each parking space. The data from these sensors are then transmitted to a central server through IoT technology. Users can access this information through a mobile application or a web interface, enabling them to find available parking spaces easily.

For gate monitoring, two IR sensors are employed at the entry and exit gates of the parking area. These sensors detect incoming and outgoing vehicles, allowing the system to monitor the occupancy status of the entire parking facility accurately. An intelligent algorithm manages the opening and closing of gates in response to the vehicle’s movement, ensuring smooth traffic flow within the parking area.

BLOCK DIAGRAM

HARDWARE COMMMPONENTS

  • ARDUINO (MICRO CONTROLLER)
  • IR SENSORS (X6)
  • 3V3 REGULATOR
  • Wi-Fi (ESP8266 NODE MCU)
  • LCD DISPLAY
  • POWER SUPPLY
  • SERVO MOTOR (FOR GATE OPEN/CLOSE)
  • JUMPER WIRES

SOFTWARE

  • ARDUINO IDE
  • EMBEDDED C
  • C PROGRAMMMING


Hi, guys if you want customizations in our projects you can contact us on WhatsApp us

Some Customization suggestions: Like IOT, Solar, Ml integration, Additional sensors, GPS GSM etc.
